Description
Features
With its one piece design, Graco’s GL-43 oil injector systems are easy to design, fast to set up and allow you to add or subtract lube points without having to redesign your lubrication system. Handles low viscosity lubricants.
Accurate, reliable lubrication for every lube point on your machine
- Longer lasting seal design for trouble-free performance
- Precision-honed components for reliable operation in challenging environments
- Adjustable output volume from 0.02–0.13 cm³ (.001–.008 in³) to custom fit the system to meet the needs of each lube point
- Convenient front-mounted cycle pin indicator for quick confirmation that the injector is functioning properly
- Operating pressures from 52-69 bar (750-1000 psi) for optimal performance with low viscosity lubricants (#10 weight minimum)
- Offered both as a stand-alone injector and replacement injector for manifold systems, allowing you to custom fit the injectors to your applications
Specifications
UPC Product: 00633955584693 Family Code: FAMMPM Unit of Measure: EA Height: 2.4 IN |6.096 CM Length: 11.176 CM |4.4 IN Width: 3.8 IN |9.652 CM Volume: .023 FT3 |.001 M3 Chargeable Weight: .96 LBS | .44 KG
Technical Specifications
| Adjustable | Adjustable |
|---|---|
| Compatible Material | Oil |
| Cycle Indicator | Visual Pin |
| Inlet Size (cm) | 0.3175 |
| Inlet Size (in) | 1/8 |
| Inlet Size (mm) | 3.175 |
| Inlet Thread Type | BSPP |
| Material | Carbon Steel |
| Maximum Working Pressure (bar) | 68.9 |
| Maximum Working Pressure (kPa) | 6890 |
| Maximum Working Pressure (psi) | 1000 |
| Minimum Working Pressure (bar) | 53 |
| Minimum Working Pressure (kPa) | 5300 |
| Minimum Working Pressure (psi) | 750 |
| Outlet Size (cm) | 0.6 |
| Outlet Size (in) | 0.236 |
| Outlet Size (mm) | 6 |
| SAE Grade | 10 |
| Type | Oil Injector |
| Compatible Metering Device | Single Line Parallel |
| Application | On-Road Vehicles, Off-Road Equipment |
| Maximum Working Pressure (MPa) | 6.9 |
| Minimum Working Pressure (MPa) | 5.3 |
| Model | GL-43 |
