Description
Features
Lubrication is critical to your vehicle’s peak performance. With Graco’s Grease Jockey automatic lubrication system, vehicle maintenance gets a whole lot easier. Take the hassle out of manually lubricating your chassis and continuously lubricate it instead.
-
Benefits:
- Keeps your chassis operating, even in harsh on-road conditions
- Lubricant goes where it’s supposed to, automatically, with little or no waste, while the vehicle is operating
- No wasted time, no missed lube points and no under or over greasing ever again!
- Systems to fit most OEM on-road vehicles, including specialty fire trucks, cement trucks and waste haulers
- Field-proven – some of the largest fleets have been using Grease Jockey for decades!
-
Ruggedized Construction
- U.V., chemical, and high-impact resistant – rigorously tested and field-proven.
-
NLGI #2 Compatible
- NLGI #000 to #2 and 2000 psi (138 bar).
-
Low Level Signal
- Alerts when out of grease.
-
Electrical Drive
- 12 VDC (7 Amp) power. Protected against motor burn-out.
-
Integrated Controls
- Includes adjustable ON/OFF times, PIN code lockout, and on-panel alerts.
-
Data Management System
- Track critical lubrication data. Fast programming.
-
In-Cab Feedback
- Tri-color LED system feedback indicator with Manual Run button.
Specifications
UPC Product: 00755652653875 Family Code: FAMGJP Unit of Measure: EA Height: 15.25 IN |38.735 CM Length: 12.5 IN |31.75 CM Width: 10.75 IN |27.305 CM Volume: 1.186 FT3 |.034 M3 Chargeable Weight: 20.4 LBS | 9.25 KG
Technical Specifications
| Type | Electric Piston Pump |
|---|---|
| Application | On-Road Vehicles |
| Compatible Material | Grease |
| Fluid Outlet Size (in) | 0.5625 |
| Fluid Outlet Size (mm) | 14.2875 |
| Fluid Outlet Thread Type | SAE ORB |
| Includes | Grease Jockey 电动泵, Electric Grease Jockey Pump, Bomba eléctrica Grease Jockey, 30 英尺（9 米）电源线, 30 ft (9 m) Power Cable, cable de alimentación de 30 pies (9 m), 手动运行按钮, Manual Run Button, botón de funcionamiento manual, 数据管理系统, Data Management System, sistema de gestión de datos |
| Maximum Fluid Output Pressure (psi) | 2000 |
| Maximum NLGI Grade | #2 |
| Maximum Working Pressure (bar) | 137.9 |
| Maximum Working Pressure (kPa) | 13790 |
| Maximum Working Pressure (psi) | 2000 |
| Model | Grease Jockey |
| Power Type | Electric |
| Reservoir Size (gal) | 0.528 |
| Reservoir Size (L) | 2 |
| Voltage (V dc) | 12 |
| Wetted Material | Nylon, Amorphous Polyamide, Zinc-Plated Steel, Carbon Steel, Alloy Steel, Stainless Steel, Nitrile Rubber, Bronze, Nickel Plated Alnico, Chemically Lubricated Acetal, Aluminum, PTFE |
| IP Rating | IP69K |
| Maximum Flow Rate (ci/min) | 0.6 |
| Maximum Voltage (V dc) | 16 |
| Minimum Voltage (V dc) | 9 |
| Number of Pump Elements | 1 |
| Maximum Working Pressure (MPa) | 13.8 |
| maximum_fluid_output_pressure_bar | 138 |
