FiTech 750HP Oval Port EFI 4150 Flange Classic Black (30-11-615)

Description

The FiTech 750HP Oval Port EFI 4150 Flange Classic Black (30-11-615) is a comprehensive electronic fuel injection solution designed to enhance the performance and efficiency of Big Block Chevy engines with oval port cylinder heads. This kit provides a complete intake system with a single 4-barrel throttle body, multi-port fuel rails, and an electronic control module (ECM). It supports up to 750 horsepower on gasoline and is compatible with various fuels, including E85, methanol, and flex fuels. The system offers both self-tuning and user-tunable capabilities, allowing for optimal performance in various engine configurations.

KEY FEATURES AND BENEFITS:

• Provides precise fuel delivery: For improved engine performance and efficiency.
• Supports up to 750 horsepower: On gasoline, with compatibility for other fuel types.
• Includes a complete intake system: With throttle body, fuel rails, and ECM.
• Offers both self-tuning and user-tunable capabilities: For optimal engine management.
• Features a 4.5-inch display: For monitoring and adjusting engine parameters.
• Includes a comprehensive sensor suite: For accurate engine data.
• Allows for timing control.

SPECIFICATIONS:

• Maximum Horsepower (Gas): 750 HP
• Injection Style: Multi-port
• Throttle Body Mounting Flange: 4-barrel square bore (4150 flange)
• Airflow Rate: 1000 CFM
• Injector Size: 55 lbs/hr
• Venturi Diameter: 44 mm or 60 mm (verify before purchase)
• Fuel Compatibility: Gasoline, E85, Methanol, Flex
• Metering Style: Speed density (Map-N) or speed throttle (Alpha-N)
• Intake Material: Aluminum
• Engine Block Deck Height: Standard deck
• Compatibility: Big Block Chevy Engines with Oval Port Cylinder Heads

HOW TO USE:

• Preparation: Ensure your engine is compatible with the FiTech 30-11-615 system. Disconnect the battery.
• Intake Installation: Remove the existing intake manifold. Install the FiTech intake manifold, ensuring proper gasket placement and torque specifications.
• Throttle Body and Fuel Rail Installation: Attach the throttle body and multi-port fuel rails to the intake manifold. Connect the fuel injectors.
• Sensor Installation: Install the MAP, IAT, TPS, and IAC sensors. Connect the oxygen sensor to the exhaust system.
• Wiring Harness Connection: Connect the wiring harness to the ECM and all sensors, following the provided wiring diagram.
• ECM Setup: Mount the ECM in a suitable location. Connect the 4.5-inch display.
• Fuel System: Install a compatible fuel pump and connect the fuel lines to the fuel rails. A fuel pressure regulator is required.
• Initial Setup: Reconnect the battery. Follow the on-screen instructions on the 4.5-inch display for initial setup and calibration.
• Tuning: Start the engine and allow the self-tuning feature to adjust parameters. Fine-tune as needed using the display.

BENEFITS OF USING THE FITECH 750HP OVAL PORT EFI 4150 FLANGE CLASSIC BLACK (30-11-615):

• Improved Engine Performance: Enhanced horsepower.
• Enhanced Fuel Efficiency.
• Precise Fuel Delivery: For optimal combustion.
• Easy Installation and Setup: With self-tuning capabilities.
• Flexibility to Use Various Fuel Types.
• Ability to Control Timing.

FEATURES:

• Single 4-barrel throttle body design.
• Multi-port fuel injection system.
• Comprehensive sensor suite (MAP, IAT, TPS, IAC, Oxygen).
• Aluminum intake manifold.
• 55 lbs/hr fuel injectors.
• Wiring harness included.
• Calibration Module Included.
• 1000 CFM throttle body.
• Speed density or Alpha-N metering.
