Description
The Cosen AV-2026NC Horizontal Band Saw is designed for high precision and efficiency in industrial cutting applications. This advanced machine offers versatile cutting capacities with adjustable blade angles, ensuring it can handle a wide range of materials with ease. With robust motor power, ample coolant and hydraulic capacities, and a user-friendly workbed height, the AV-2026NC is built to deliver superior performance in demanding environments.
- Cutting Capacities:
- At 0° Blade Cant: 20″ x 26.3″
- At 45° Left: 20″ x 18.1″
- At 60° Left: 20″ x 12.2″
- At 45° Right: 20″ x 16.5″
- At 60° Right: 20″ x 11.2″
- At 5° Blade Cant (0° Angle): 20″ x 24.8″
- At 5° Blade Cant (45° Left): 20″ x 16.9″
- At 5° Blade Cant (60° Left): 20″ x 11.4″
- At 5° Blade Cant (45° Right): 20″ x 14.9″
- At 5° Blade Cant (60° Right): 20″ x 9″
- Blade Specifications:
- Speed: Variable blade speed from 66 to 328 FPM
- Size: Blade dimensions are 17′ 1.9″ in length, 1.25″ in width, and .042″ in thickness
- Motor: Powered by a 7.5 HP blade motor for high-performance cutting
- Cooling and Hydraulic System:
- Coolant Motor: 1/4 HP to maintain blade temperature
- Coolant Tank Capacity: 34.3 gallons for extended operation
- Hydraulic Tank Capacity: 22.4 gallons for efficient hydraulic function
- Dimensions and Weight:
- Workbed Height: 40.5″ for ergonomic use
- Weight: A solid construction weighing 8,518 lbs
- Floorspace: Requires 205″ x 147″ x 102″ space
Please Note: This product cannot be returned.
