Description
The BRICK® Model 9610 | Portable Explosion Proof Area Light
The most versatile and rugged LED portable explosion proof area light on the market. Built for a variety of applications ranging from aviation, tank entry, power generation, refineries, and blast & paint. Built from a solid block of 6061-T6 Aluminum for durability. Variable intensity light control (dimmer switch) option available. Thermally controlled for comfortable handling.
The BRICK® is certified and approved for hazardous locations (HazLoc):
- Class I, Div 1 & 2, Groups C & D;
- Class II, Div 1 & 2, Groups E, F, & G
- CSA Zones 1 & 2; Zones 20,21 & 22
- Portable Luminaire (UL 153)
- Wet Location
- Low Voltage (LVLE)
Additional Features:
* Variable intensity light control (Option Available)
* Thermally controlled for comfortable handing
* Bend Radius Sleeves (patent pending) – strain relief for electrical cord connections
| Approved for: | Class 1, Div 1 & 2; Groups C & D Class II, Div 1 & 2; Groups E, F, & G CSA Zones 1 & 2; Zones, 20, 21, & 22 |
| Conforms to: | UL Stds 153, 781, 844 |
| Certified to: | CSA Stds C22.2#s 12, 25, 137 |
| Suitable for: | Wet Location Use – the BRICK®, as a Hazardous Location Luminaire, is constructed for continuous usage in Class I & II, Division 1 & 2 environments. Further, critical design tolerances ensure that each enclosure is fabricated to be dust proof and watertight. Submersion testing is taken to a depth of 100 feet in water verifying waterproof construction, which easily meets and exceeds NEMA Type 6P certification requirements. |
| Certified: | Portable Luminary (Portable Luminaire) |
| Temperature Rating: | T-Code: T5 (-20°C to +40°C); T4 (-20°C to +100°C) |
| LEDs Color: | ~6000K, CRI >70 |
| Light Output: | 50,000 Lux at 1ft; >11,500 lumens |
| Reflective Optic Beam Angle: | 60° |
| Light Head Power: | 36VDC, 2-3A |
| Dimensions: | Light head with Handles & Bumpers: 12¾” x 6⅛” x 5¼” Bend Radius Enforcement Sleeve (connecting the cord to the lighthead): 10.1875″ x 1.5625″ |
| Body Material: | Machined out of solid block of 6061-T6 Aluminum |
| Protection: | Polyurethane Bumper |
| Multiple Mounting Options: | Flexible Mechanical & Magnetic mounting (See Mounting Options) |
| Country of origin: | Designed & Manufactured in the USA |
