Description
Baileigh JMD-18 Mill/Drill with Acu-Rite 203 DRO 2HP 115/230V 1Phase (350401) combines a belt-driven drill press with the dual coordinate abilities of a milling machine’s table for flexibility and efficiency. The mill drill features a locking collet to prevent the cutting tool from falling away from the spindle during lateral forces, offering space-saving versatility and light machining capability.
This Baileigh 350401 2HP mill drill includes a one-piece cast iron column for added support, a belt cover with a quick slide latch for faster belt adjustments, and a large worktable for accommodating bigger projects.
- Specifications and Dimensions
- Digital Readout: ACU-RITE VUE
- Drilling Capacity: 1-1/4 in.
- Face Mill Capacity: 3 in.
- End Mill Capacity: 3/4 in.
- Swing: 15-7/8 in.
- Max Distance Spindle to Table: 18 in.
- Spindle Taper: R-8
- Spindle Travel: 5 in.
- Quill Diameter: 3 in.
- Column Diameter: 4-1/2 in.
- Number of Spindle Speeds: 12
- Range of Spindle Speeds: 150 – 3,000 RPM
- Table Size (L x W): 9-1/2 x 31-3/4 in.
- Table Longitudinal Travel: 20-1/2 in.
- Work Table Weight Capacity: 400 lbs.
- T-Slots Number and Size: 4, 5/8 in.
- T-Slot Centers: 1-13/16 in.
- Base Dimensions: 15-3/4 x 23-3/4 in.
- Motor: 2 HP, 115/230V, 1Ph
- Overall Dimensions (L x W x H): 47 x 40 x 51 in.
- Weight: 600 lbs.
- Key Features and Benefits
- One-piece cast iron column for added support
- Quick slide latch for faster belt adjustments
- Large worktable for bigger projects
- Locking collet to prevent tool fall
- Equipped with Acu-Rite VUE digital readout
- Space-saving and versatile for light machining
