Description
The AIMS Power 10 AWG PV Wire Unlugged – Price Per Foot – Black (PVD653T-B-10AWG) is specifically designed for reliable performance in solar energy systems. This durable cable features a red outer insulation, making it easily identifiable in installations. This wire is suitable for a variety of photovoltaic applications. It is built to withstand extreme temperatures, with a rating of up to 90 °C and can operate efficiently in environments ranging from -40 °C to +90 °C. The robust construction ensures longevity, with TÜV certification indicating it can perform for over 25 years. The wire’s design includes a minimum bending radius of five times its outer diameter, making it versatile for various installations.
Specifications:
- Wire Color: Red
- Voltage Rating: 600 V
- Temperature Rating:
- 90 °C dry or wet
- 194 °F dry or wet
- Ambient temperature:> 25 years (TÜV)
- Operating Range: -40 °C to +90 °C (-40 °F to +194 °F)
- Max Short Circuit Temperature: 250 °C (+482 °F)
- Bending Radius: ≥ 5 × outer diameter
- Structure: 75/0.30 TC
- Conductor Diameter: ID 3 mm
- XLPE Thickness: 1.6 mm
- Jacket Diameter: OD 6.2 mm
- Weight: 5.6 lbs per 100 ft
- Allowable Current: 49.6 A
- Conductor Resistance: 3.59 Ω/km
- Certifications: UL854, VDE 0295, IEC 60288, TÜV
