Description

5140147 R980AT Swing-Arm Tire Changer W/Assist / 208-240V, 1-Ph., 50/60hz / GRAY-YELLOW

The R980AT saves an impressive amount of space, making it ideal for small or cramped tire shops. Because it utilizes a swing-arm design and doesn’t tilt back, it can be installed flush against a wall. An assist tower will help with stiffer sidewalls, run-flats and other low-profile tires. 30″ clamping ability.

Features

Air Requirement 140 – 165 psi (10-11 BAR)
Wheel Clamping Method
4 Clamps – Internal / External
Table Clamping System
Dual Pneumatic Cylinders
Bead Breaking System
Pneumatic Blade / Dual Settings
Power Assist Towers
Single Assist Tower
Tool Holder
Manual Lock
Inflation Gauge With Integrated Air Dump Valve
Inflation Pressure Regulator/Limiter
Water Filter
Oiler / Lubricator
Air Regulator
Breaker Bar
Large Soap / Lubricator Bucket
Brush
Tower Design
Rigid Fixed / Swing Arm
Bead Lifting Roller(s)
Single Lifting Roller
Alloy-Steel Mount/Demount Head
Plastic-Polymer Mount/Demount Head
Upper Bead Assist Roller
Traveling Drop-Center Hold Down Device
Inflation Restraint Device
Bead Seating System
Turbo Blast / Bead Seating
Tool Tray / Bin Storage
Motorcycle Turntable Clamps (Optional)

Style:	Fixed Tower Design
Assist
Assist Type:	Single-Tower Assist
Speed
Speed:	Standard
Motor	3 HP (220 VAC 50-60 HZ)
Drive System Type	Electric / Air
Air Requirement	140-165 PSI (10-11 BAR)
Wheel Clamping Method	4 Clamps – Internal / External
Table Clamping System	Dual Pneumatic Cylinders
Bead Breaking System	Pneumatic Blade / Dual
Tower Design	Rigid Fixed / Swing Arm
Power Assist Towers	Single Assist Tower
Bead Lifting Roller(s)	Single Lifting Roller
Bead Seating System	Turbo Blast / Bead Seating
Internal Rim Clamping Capacity	10” – 30” (254 mm – 762 mm)
External Rim Clamping Capacity	9” – 28” (229 mm – 711 mm)
Turntable Tire Width Capacity (Mounting)	4” – 18” (102 mm – 457 mm)
Bead Breaker Tire Width Capacity (Demounting)	1.5” – 13” (38 mm – 330 mm)
Maximum Tire Diameter	50” (1,270 mm)
Shipping Weight	900 lbs. (408 kg)
Shipping Dimensions	51” x 45” x 73” (1,295 mm x 1,143 mm x 1,854 mm)
